Pivot Doors
Transform Your Space with a Bold Entrance
What is a Pivot Door?
A Pivot Door is a modern alternative to a traditional hinged door. Instead of swinging open on side-mounted hinges, a pivot door rotates on a concealed pivot point set into the top and bottom of the frame. This creates a smooth, dramatic motion that feels both effortless and sophisticated.
Because the pivot hardware supports the weight from the floor, pivot doors can be built much larger than standard doors, making them a striking choice for entryways, interior passages, wine rooms, or anywhere you want to make a bold architectural statement.
At ActivWall, our custom Pivot Doors are precision-engineered to combine beauty with performance. Each one is built to order with your choice of size, finish, and hardware so it complements your space perfectly. Whether you prefer an inswing or outswing configuration, our Pivot Doors deliver style, strength, and lasting durability.
Why choose an ActivWall Pivot Door?
- Smooth, seamless function – Precision craftsmanship and our state-of-the-art motion hardware ensure effortless operation
- Custom-built for you – Each unit is tailored to your exact size, finish, and material preferences
- Indoor-outdoor flow – Maximize light, space, and movement with self-closing technology and the ability to hold positions at -90° | 0° | +90°
- Quality Craftsmanship – Designed and built in the USA with high-quality, energy-efficient materials, each unit is backed by a comprehensive 10-Year Residential or 2-Year Commercial Warranty
Want to discover more? Schedule a no-pressure consultation to learn more about Pivot Doors and how they can enhance your space.
Ready to Customize Your Pivot Door?
If you’re ready to bring your vision to life, our streamlined process makes it easy to design a Pivot Door that’s perfect for your project. Whether for a home, office, or commercial space, every ActivWall Pivot Door is built to order, handcrafted to your specifications, and delivered with care. Follow these prompts to plan your perfect Pivot Door.
Overview
This video overview of our customization options will walk you through each step.
System
ActivWall Pivot Doors, are available in three frame systems, depending on whether the unit will be used in an interior or exterior setting.
Exterior Use
• Thermally Broken Aluminum (standard): Frame components provide strength, durability, and flexibility for unique design possibilities. Each unit gets commercial-grade aluminum, even in residential settings. This standard system features thermal breaks for maximum energy efficiency.
• Wood-Clad Aluminum: This system combines the warmth and beauty of wood on the interior with the strength and low maintenance of thermally broken aluminum on the exterior. Combining various wood species on the inside with aluminum finishes on the outside makes design possibilities virtually limitless. The modified aluminum profile accepts a snap-in wood component that can be painted or stained according to the customer’s preference.
Interior Use
• Aluminum: This aluminum system offers the same high-quality frame material as our standard system without thermal breaks. This option is best suited for interior room dividers or other environments that don't require climate control or insulation.
Size
ActivWall Pivot Doors are available in sizes up to 6' wide and 10' high. Larger sizes are possible with the addition of mullions and multiple unit configurations are also available.
How to Measure:
The width of the “rough opening” is the measurement used – from stud to stud. For the height, the measurement begins at the header and runs to the bottom of the sill channel. If there is currently another door in place, the inside measurements of the current door frame (not the glass) will typically work, although be sure to speak to your ActivWall sales rep about this – images of the opening may be needed to determine the correct measurements.
Structural Design
The ActivWall Pivot Door features durable hidden motion hardware that self-closes with -90° | 0° | +90° hold positions. The placement of the pivot point can be customized to your unique project, and you can also choose an inswing or outswing configuration.
ActivWall Pivot Doors can be made as a single panel or with horizontal or vertical mullions. While mullions are required for larger doors, they are often chosen as a desirable design feature for doors of all sizes.
Pivot Doors can also be ordered with two panels to create a French Door effect.
Note: Simulated Divided Lite (SDL) options are covered under Glazing.
Sill
We offer four structural sill options for ActivWall Pivot Doors:
• Saddle Sill - Offers a high structural performance. It is air and water-resistant with weep holes for controlled water exfiltration. Suitable for Interior and exterior applications.
• Flush Sill - Offers a more minimal look. Has weep holes for controlled water exfiltration, but offers less air and water protection than the above options.
• U-Channel Sill - For interior applications only, this sill is compatible with a variety of configurations, but offers the lowest air and water performance.
• Low Profile Saddle Sill - For interior applications only, this sill is compatible with a variety of configurations. Unlike the saddle sill, It does not offer controlled water exfiltration.
Glazing
The aesthetic of your space is important. Our relationship with several trusted vendors enables us to offer a wide variety of glazing options.
Our Insulated Dual-Pane Low-E Argon-Filled Glass comes standard, offering superior thermal efficiency and comfort. For interior installations where energy efficiency is not a priority, we also offer single-pane glass, providing elegant simplicity for spaces such as sunrooms, offices, and partitions.
For those who desire an elevated level of personalization or performance, we offer premium glass enhancements, including:
• Tinted Glass
• Frosted Glass – Designed for privacy. It can also be used as a writable dry-erase surface.
• Textured Glass
• Printed Glass
• Bird-Resistant & Turtle Safe Glass – These options combine safety with sustainability.
• Impact-Resistant Glass – Engineered for strength and peace of mind in coastal or hurricane-prone regions.
To further enhance aesthetics, you can also add SDLs and GBGs in any pattern. We recommend pairing SDLs and GBGs for the optimal look.
• Simulated Divided Lites (SDL) – narrow metal grids on the exterior of the glass mimic the look of traditional divided lites.
• Grille Between Glass (GBG) – narrow metal grids sandwiched between two layers of glass to complete the look.
Handle & Hardware
The ActivWall Pivot Door comes with a standard 48" pull bar. Premium full-length pull bars or European mortise handles that offer a secure three-point locking mechanism are available for an additional charge. Additional architectural hardware options are also available upon request.
Pull bars and handles can be finished in the same color as your frame or in a contrasting color for added interest.
Finish
Standard finishes of white, black, and dark bronze are available at no additional charge. Depending on your frame style chosen, ActivWall products can be customized with various other powder coat, anodized, simulated wood-grain, and wood-clad finishes.
• Powder Coat: We offer a range of durable and eco-friendly powder coat finishes available in a selection of vibrant color choices to meet your needs, and we can find and/or match virtually any color for an additional fee.
• Wood Grain Powder Coat: Get the warm look of wood applied to your low-maintenance and durable aluminum system. Wood grain powder coat finishes by Decoral are now available. Just as natural wood species may have distinct color and grain variations, these very realistic simulated finishes can also display character.
• Dual-Tone Finishes: Mix and match your favorite finishes on the interior and exterior of your unit to create a truly custom look.
• Coastal/Poolside Finishes: If your unit will be near a swimming pool or the ocean, ask your sales rep about adding a protective coastal/poolside finish. This consists of a corrosion-protective primer as a base coat and an opaque weather-resistant topcoat. The finish provides excellent corrosion resistance in harsh environments.
• Anodized Finishes: These are primarily used in commercial applications and provide an attractive appearance to match different architectural styles.
Additional Features
A variety of add-on features are available to fully customize your ActivWall Pivot Door.
• Additional Fixed Panels - Complete the look with transoms, side lites, or panels designed to coordinate with your Pivot Door.
• Kick Plates - For added protection in high-traffic areas, kick plates can be added to your door.
Request a Free Quote
You’re one step away from a show-stopping pivot door built just for you. Contact us today for a free quote and let us help you transform your space.
